LM3886 x2 + opamp preamplifier 68W 4 ohm amplifier PCB

Write a Review

Brand:
Unbranded/Generic
MPN:
Does Not Apply
$9.99






This is the PCB of a stereo power amplifier using NS's renowned LM3886 power amplifier chip. The circuit contains a preamplifier stage. Either popular NE5532 or other high performance opamps can be used.



Product Specifications:



Output Power:68W x 2(4Ω)



Operating voltage :28V-0-28V



Operating type : Class AB type amplifier.



Input Impedance:47K



Output Impedance:4-8Ω



Features :



PCB size:117 mm x 95 mm; PCB thickness 1.6mm; 2 ounce thick copper plating.







This is a stereo amplifier.



We provide schematic and part list for this auction.



The assembled amplifier picture is attached for reference.
